- Temperature Range:
250 ~ 2500°C (482 ~ 4532°F) (MB 25)
250 ~ 1800°C (482 ~ 3272°F) (MB 18)
- Optics: Manually focusable between 210 ~ 5000 mm
- Spectral Ranges: 1.45 ~ 1.8 μm
- Resolution:
0.1°C or 0.2°F at interface
<0.0015% of selected sub range at analog output, min. 0.1°C, 16 bit; 1°C or 1°F on display
- Emissivity ε: 0.050 ~ 1.000 in steps of 1/1000
- Transmittance τ: 0.050 ~ 1.000 in steps of 1/1000
- Response Time t90: 120 μs (for IGA 6 Advanced, it is recommended for measuring temperatures below 300°C to set a response time of 1 ms (min)); adjustable to min; 1 ms, 3 ms, 5 ms, 10 ms, 50 ms, 250 ms, 1 s, 3 s, 10 s
- Measurement Uncertainty (κ = 1, t90 = 1 S, Tamb. = 25°C):
300 ~ 1500°C: 0.3% of reading in °C + 2°C
>1500°C: 0.6% of reading in °C
- Repeatability (κ = 1, t90 = 1 S, Tamb. = 25 °C): >300°C: 0.15% of reading in °C + 1°C
Optical Specifications:
- Sighting: Built-in laser aiming light (max. power level < 1 mW, λ = 630 to 680 nm, CDRH class II) or through-lens sighting
- Optics: Manually focusable from rear cover measuring distance a = 210 to 5000 mm
- Distance Ratio: Approx. 350:1
Electrical:
- Power Supply: 24 VDC ±25%, ripple must be less than 50 mV
- Power Consumption: Max 3 W (incl. laser)
- Load (analog output): 0 ~ 500 Ω
Environmental
- Protection Class: IP 65 IEC 60529 (value in mated condition)
- Ambient Temperature: 0 ~ 70°C (32 ~ 158°F)
- Storage Temperature: -20 ~ 80°C (-4 ~ 176°F)
- Weight: 0.6 kg
- Housing: Stainless steel
- CE Label: According to EU directives about electromagnetical immunity
Interface:
- Connection: 12-pin connector
- Display (in rear cover): LED, 4 digit matrix, 5 mm high-temperature signal or measuring distance
Communication
- Analog Output: 0Adjustable 0 ~ 20 mA or 4 ~ 20 mA, linear (via digital interface)
- Digital Interface: RS485 addressable (half-duplex)
Baud rate: 1200 Bd to 115.2 kBd (on request RS232, not addressable)
- Scope of Delivery: Pyrometer with PC software InfraWin for adjustment and evaluation, Works Certificate, and Manual
