CPU: Microchip DS PIC
Protocol: RS485, Modbus RTU Mode
Accuracy:
+ DC Signal：≤±0.1%
+ RTD PT100Ω：≤±0.2%
+ T/C：≤±0.5%
Sampling rate: 1times/ sec (16 chanel)
Input range:
+ Voltage: (0)1~5V /0~10Vdc
+ Current: (0)4~20mA DC
+ RTD:PT100Ω(Max 800℃)
+ T/C：K、J、E、T Type (Max 1200℃)
Analogue input: 8 OR 16 Channels
Resolution: 16 bits ADC
RS485:
+ Address: 1~255
+ Baud rate: 1200/2400/4800/9600/19200/38400 bps
+ Data: 8 bits
+ Parity check Even, odd or none
+ Stop Bits: 1bits or 2bits
Power: DC24V(18~36Vdc)
Dimensions 242(L)x122(W)x56.9(With Cover:70)(h) mm
Temperature: 0~60 ˚C
Humidity: 20~95 %RH
Weight: 500g
APPLICATIONS
- Analogue data collector
- Remote sensing and metering
- Environment condition detection
- Data recording
