Adtek MT-RTD Rtd Transmitters

- Input Range: Pt100Ω -100 ~ 800°C
- Input Impedance: ≥ 10MΩ
- Output Range: -10 ~ 0 ~ +10 V / 0~20mA
- Accuracy: ±0.1%
- RTD type: DIN Pt100Ω, JIS Pt100Ω
- Sensing current: About 1.5 mA
- Response time: ≤ 250 mS
- Power Supply: AC 115 or 230V ±10%, 50/60 Hz
- Dimensions: 50mm(W) x 87mm(H) x 123mm(D)-with socket
- Weight: 600g
- Option: Pt100

Select the bottom ordering

Datasheet

Option
- Input Range
- Output range (V or mA)
- Aux Power: AC 115V or AC 230V
- RTD type Cu10, Ni120
