Measuring range and Accuracy (at23*C±5*C) *D＜1 series equivalent circuit
Range/ Measuring range/ Measuring voltage/ Accuracy
1/ 100nF～ 999nF/ less than 100mV/ within ±0.25％± (1＋10D) digit
2/ 1μF～ 9.99μF/ less than 100mV/ within ±0.25％± (1＋10D) digit
3/ 10μF～ 99.9μF/ less than 100mV/ within ±0.25％± (1 ＋10D) digit
4/ 100μF～ 999μF/ less than 100mV/ within ±0.3％± (2 ＋10D) digit
5/ 1mF～ 9.99mF/ less than 100mV/ within ±0.5％± (3 ＋10D) digit, ±CS (mF) /1mF digit
Measuring method:5-terminal configuration with guard terminal
Measuring frequency: 120Hz ±0.1%, SINE wave
Measuring time:
[Remote start mode] 10msec.
[Free running mode] 50 times per second
Display of measured value (deviation):－79.9％～＋99.9％
Comparator set range:upper limit：＋0.0％～＋99.9％, lower limit：－0.0％～－79.9％
Indication of comparator's comparison result: LED indication -NG, GO, +NG and buzzer
Control signal:remote start input:
comparison output [LO/GO/HI]：open collector：max.50V, 100mA
end of comparison output [EOC]：open collector：max.50V, 100mA
BCD parallel output of measured value：fan out 2
Power supply:AC100V～240V selectable, 50/60Hz, about 20VA
Outer dimension: about 260 (W) ×90 (H) ×250 (D) mm (excluding protruding parts such as rubber legs, etc.)
Weight: about 2.6kg
