Specifications
Number of digits for generation: 4½
Output method: Bipolar
Maximum output voltage: ＋250 V, －15 V/320 mA
Minimum voltage resolution: 100 μV
Maximum output current: ±320 mA/＋250 V, －15 V
Minimum current resulution: 100 pA
Number of digits for measurement: 5½
Accuracy (typical range): 0.0002
Minimum measurement voltage resolution: 10 μV
Minimum measurement current resulution: 10 pA
Maximum measurement resistnace / Minimum resolution: 125 GΩ/30 μΩ
Pulse application / Measurement: Available
Minimum pulse width: 50 μs
Interface: USB, GPIB
Supplied Accessories:
Power cable (JIS 2 m): 1
Input and output cable (safety plug): 1
Banana tip adapter (for A01044): 1
Alligator clip adapter (for A01044): 1
