Power (KVA): 12
Voltage Range (LN_AC): 0-450
Frequency Range (Hz): 0.001-200
3-Phase/ pre-phase MAXIMUM CURRENT(A) :
+ (RMS): 35
+ (peak): 105
1-Phase MAXIMUM CURRENT(A):
+ (RMS): 105
+ (peak): 315
Voltage Range (V_DC): ±636
Current Range (A_DC）: ±105
Heigh: 3U
Input
Wiring mode: Three-phase four-wire ABC+PE
Frequency (Hz): 47 - 63
Voltage range (V): 304 - 480
Current per phase (A_max): 22
Input peak current (A): < 1.5x rated
Power factor: > 0.99
Efficiency: > 0.91
AC Voltage Output
Accuracy: ±(0.01%+0.05% F.S.)
Resolution: 0.01V
Load Regulation: ±0.05% F.S.
Line Regulation: ±0.01% F.S. @10%
Voltage Slew Rate: AC>3.0V/μs
Voltage Distortion: <0.3%@50Hz/60Hz; <1%@0.001Hz-200Hz
Voltage Compenstion: Adaptive
DC Voltage Output
Accuracy: ±(0.01%+0.05% F.S.)
Resolution: 0.01V
Load Regulation: ±0.05% F.S.
Line Regulation: ±0.01% F.S. @10%
Voltage Slew Rate: DC>3.0V/μs
Frequency Output
Accuracy: ±0.01%
Resolution: 0.001Hz
Range: 0.001 - 200Hz
Phase Angle Control
Accuracy: ±0.1°@0.001-200Hz
Resolution: ±0.1°
Phase Angle Range: 0 - 359.9°
Phase Control: Single-phase, Three-phase, Three-phase independent
Harmonin Injection
Range: up to 100th order @ 40-70Hz fundamental frequency;
Content: up to 25th order @ 70-200Hz fundamental frequency; 40%
Magnitude Error: ±5%@ set value or 0.1% of the fundamental frequency;
Current
Accuracy: ±(0.1%+0.1% F.S.)
Resolution: 0.01A
Internal Resistance Mode
R range (Ω) : 0-10: L range (mH) ; 0-2
Resolution : 0.001 : Accuracy : ±0.01%+0.02% F.S.
RLC load
Resistance range (Ω) : 0.001 to 1000; Resistance resolution (Ω)) : 0.001; Resistance accuracy : ±0.1% F.S.
Inductors range (mH) : 0.1 to 5000; Inductors resolution (mH) :0.001; Inductors accuracy : ±0.1% F.S.
Capacitance range (mF) : 1 to 5000; Capacitance resolution (mF) : 0.1; Capacitance accuracy : ±0.1% F.S.
Crest factor range : 1.000 to 5.000; Crest resolution : 0.001
Power factor range : -1.000 to 1.000; Power resolution : 0.001
Transient Functions
Programming: List, Wave, Step, Pulse, Advanced, Harmonics, Inter-harmonics, DST
Time of Step Resolution: 100μs
Number of Programmed Waveforms: 100
Anolog Programming: RMS, Amplitude, Instantaneous value(Amplifier mode)
Environmental
Cooling: Air cooled
Temperature: Operating : 0 to 50°C; Storage : -20 to 70°C
Humidity: <80%, non-condensing
Dimension & Weight:
Dimension (mm): 435(W) x 132(H) x 781(D)
Weight: 35kg
