Lamination method: Z-shaped lamination
Operation method: Manual feeding, manipulator collects the stacks and automatically pulls the diaphragm
Lamination accuracy, alignment precision: ≤±0.3 mm
Lamination range: Battery Min. L62 mm × W46 mm, Max. L200 mm × W200 mm, without tabs
Lamination thickness: Max. 30 mm
Number of laminated layers: Max. 500 layers (settable)
Diaphragm roll diameter: Max. 250 mm
Diaphragm winding core: 3-inch core, pneumatic shaft clamping
Control system: Automatic servo constant tension control for diaphragm roll material
Diaphragm correction: Automatic photoelectric alignment control
Power supply: Single-phase AC 220V±10% (110VAC optional), 50Hz/60Hz, 0.6 kW
Air source: 0.5–0.8 MPa compressed air
Operating environment: 25±3℃, humidity 30–90% RH, no vibration or electromagnetic interference
Dimensions: L1100 × W790 × H755 mm
Weight: 300 kg
1. The number of laminations can be automatically controlled according to the preset;
2. Adopting compatibility design, battery size change can be realized by adjusting the positioning fixture, and the adjustment range is large;
3. PLC control, HMI operation, easy to use and maintain;
4. Pole pieces are manually loaded, automatically positioned, the robot automatically sucks the pieces, and automatically stacks;
5. Automatic servo constant tension control of coiled material diaphragm.
6. Diaphragm automatic photoelectric correction control.
