Abracon APARM2508S-SG3L5 Passive Antenna Internal/Embedded Active Patch Through Hole Pin

Gain: 0.5 dBi, 0.6 dBi, 2.4 dBi, 3.4 dBi

VSWR: 1.8

Style: Stacked

Width: 25.1 mm

Height: 8 mm

Length: 25.1 mm

Bandwidth: 3 MHz, 22 MHz

Impedance: 50 Ohms

Application: M2M, Remote Technology/Monitoring, Geofencing, Navigation, Surveying, Mapping Systems, Logistics, Precision Transportation

For Use With: GALILEO, GLONASS, GPS L1 and L5

Polarization: RHCP

Mounting Style: PCB Mount

Number of Bands: 5 Band

Center Frequency: 1.174 GHz, 1.572 GHz

Mechanical Style: Patch

Ground Plane Size: 64.76 mm x 37.64 mm, 65.36 mm x 70.88 mm

Maximum Frequency: 1.602 GHz

Minimum Frequency: 1.176 GHz

Termination Style: SMD/SMT

Protocol - Sub GHz: IoT

Protocol - GPS, GLONASS: BEIDOU, Galileo, GLONASS, GPS

Maximum Operating Temperature: + 105 C

Minimum Operating Temperature: - 40 C
