Frequency, Min (GHz): 6
Frequency, Max (GHz): 67
Gain, Typ (dBi): 13
Polarization: Linear
3dB Beamwidth, E-Plane, Min (Deg.): 10
3dB Beamwidth, E-Plane, Max (Deg.): 105
3dB Beamwidth, H-Plane, Min (Deg.): 9
3dB Beamwidth, H-Plane, Max (Deg.): 86
Cross Pol. Isolation, Typ (dB): 30
VSWR, Typ: 1.5:1
Impedance, (Ohm): 50
Power Handling, CW, (W): 5
Power Handling, Peak, (W): 10
Interface
Output Type: Coaxial
Connector: 1.85mm(V)
Connector Gender: Female
Mechanical Specification
Body Material: Al
Finish: Chemical Conversion Coating
Size, W (mm): 41.3
Size, H (mm): 41.3
Size, L (mm): 65
Weight, (kg): 0.1
