Measuring wavelength: 1270nm/1310nm/1490nm/1550nm/1577nm
Measuring range（dBm): +10～-35/ +10～-35/ +12～-40/ +25～-40/ +12～-40
Spectral passband (nm): 1270±10/ 1310±10/ 1490±10/ 1550±10/ 1577±10
Insertion loss: ≤1.5 dB
Uncertainty: ≤0.5 dB
Interface type: SC
Display resolution: 0.01dB
Fiber Type: SM 9/125um
VFL
Wavelength: 650±10 nm
Output power: 10mW
Modulation frequency: CW/1Hz/2Hz
Connector: Universal
Others
Operating temperature: -10～+60℃
Storage temperature: -25～+70℃
Relative humidity: 0%～95%RH
Communication interface: USB
Power supply: Rechargeable 3.7V lithium battery/USB
Operating time(h): Operating time ≥20H，stand-by time ≥60H
Dimension/ Weight: 173×82×37mm/ 350g
Packing List: Main Unit / USB Cord / User Manual / Power Charger
