Integrating Sphere Size: Φ154mm
Light Source: 360nm-780nm Xenon Lamp, 400nm cut-off Xenon Lamp
Spectrophotometric Mode: Concave Grating
Sensor: 256 Image Element Double Array CMOS Image Sensor
Wavelength Range: 360-780nm
Wavelength Interval: 10nm
Semiband Width: 10nm
Measured Reflectance Range: 0-200%
Measuring Aperture:
- Reflective: Φ30mm/Φ25.4mm, Φ18mm/Φ15mm, Φ10mm/Φ8mm, Φ6mm/Φ4mm;
- Transmissive: Φ30mm/Φ25mm;
- Remark: 1. Automatic identification of switch caliber 2. Customized Configuration caliber and lens position
Dimension: 370×300×200mm
Weight: Approx 9.6kg
Power: AC 24V, 3A Power adapter power supply
Illuminant Life Span: 5 years, more than 3 million times measurements
Displayed Data: 7" TFT Capacitive Screen-touch Display
Data Port: USB & Print serial port
Data Storage: Standard 2000 Pcs, Sample 20000 Pcs
Operating Environment: 0~40℃, 0~85%RH (no condensing), Altitude < 2000m
Storage Environment: -20~50℃, 0~85%RH (no condensing)
Standard Accessory: Black Calibration Board, Standard calibration plate, Sample Holder, Φ4mm, Φ8mm, Φ25.4mm Aperture, Fixing frame,Transmission blackboard, ; Power Adapter,USB Cable, User Guide, PC Software
Optional Accessory: Micro printer, transmission test component, micro hole (4mm) , transmission component, instrument inversion component
Datasheet
