Integrating Sphere Size: Φ40mm
Light Source: Combined full spectrum LED light source, UV light source
Spectrophotometric Mode: Flat Grating
Sensors: Silicon photodiode array (double row 40 groups)
Wavelength Range: 400~700nm
Wavelength Interval: 10nm
Semiband Width: 10nm
Measured Reflectance Range: 0~200%
Measuring Aperture: MAV:Φ8mm/Φ10mm;SAV:Φ4mm/Φ5mm
Specular Component: SCI/SCE
Color Space: CIE LAB,XYZ,Yxy,LCh,CIE LUV,s-RGB,HunterLab,βxy,DIN Lab99 Munsell(C/2)
Observer Angle: 2°/10°
Illuminant: D65,A,C,D50,D55,D75,F1,F2(CWF),F3,F4,F5,F6,F7(DLF),F8,F9,F10(TPL5),F11(TL84),F12(TL83/U30)
Displayed Data: Spectrogram/Values, Samples Chromaticity Values, Color Difference Values/Graph, PASS/FAIL Result, Color Simulation, Color Offset
Measuring Time: About 1.5s (Measure SCI & SCE about 3.2s)
Repeatability: Chromaticity value: MAV/SCI, within ΔE*ab 0.02 ( When a white calibration plate is measured 30 times at 5 second intervals after white calibration)
Measurement Mode: Single Measurement, Average Measurement(2-99times)
Locating Method: Camera Locating
Dimension: L*W*H=370x240x260mm
Weight: About 7.8kg
Battery: AC 24V, 3A Power adapter power supply
Illuminant Life Span: 5 years, more than 3 million times measurements
Display: 7-inch TFT color LCD, Capacitive Touch Screen
Data Port: USB, trigger switch interface
Data Storage: Standard 1000 Pcs, Sample 30000 Pcs
Language: Simplified Chinese, English, Traditional Chinese
Operating Environment: 0~40℃, 0~85%RH (no condensing), Altitude < 2000m
Storage Environment: -20~50℃, 0~85%RH (no condensing)
Standard Accessory: Power Adapter, USB Cable, User Guide, PC Software(Download from office website), White and Black Calibration Cavity, 8mm Aperture, 4mm Aperture
Optional Accessory: Micro Printer, Foot Switch, Rotating Bracket
