Optical Geometry: D/8(diffused illumination, 8-degree viewing angle), SCI (specular component included component excluded) Mode, Comply to CIE No.15,GB/T 3978,GB 2893,GB/T 18833, ISO7724-1,ASTM E1164, DIN5033 Teil7
Characteristic: Adopt CMOS dual beam splitting sensor; Used for color difference quality control in plastic electronics, paint and ink, textile and garment printing and dyeing, printing, ceramics and other
Light Source: Combined full spectrum LED light source
Integrating Sphere Size: Φ40mm
Sensor: CMOS dual beam splitting sensor
Wavelength Range: 400-700nm
Measuring Aperture: Ф4mm/5mm(Plat+Sharp Caliber)
Specular Component: SCI
Color Space: CIE LAB
Color Difference: ΔΕ*ab
Other Colorimetric Index: /
Observer Angle: 2°/10°
Illuminant: D65
Display: Spectrogram/Values, Samples Chromaticity Values, Color Difference Values/Graph, PASS/FAIL Result, Color Simulation, Color Offset
Measuring Time: About 1s
Repeatability: Chromaticity value: MAV/SCI, within AE*ab 0.02 (After preheating and correction, the average value of the whiteboard was measured for 30 times at an interval of 5s); Spectral reflectance: MAV/SCI, Standard deviation within 0.08% (400nm to 700nm: within 0.18%)
Inter-instrument Error: MAV/SCI, Within ΔΕ*ab 0.4 (Average for 12 BCRA Series II color tiles)
Displayed Accuracy: 0.01
Measured Reflectance Range: 0-200%
Reflectance Resolution: 0.01%
Measurement Mode: Single Measurement, Average Measurement(2-99times)
Locating Method: Stabilizer position
White Calibration mode: Contact type calibration
Dimension: 94X68X188mm
Weight: About 410g
Battery: Lithium battery, 3.7V,3200mAh, 8000 cycles in 8 hours
Illuminant Life Span: More than 1.2 million measurements over 10 years
Screen: 2.8 inch TFT true color, Capacitive Touch Screen
Interface: USB, Bluetooth
Data Storage: Standard 200Pcs, Sample 10000Pcs (One data is able to include SCI/SCE); APP/PC mass storage
Software support: Andriod, IOS, Windows, WeChat Mini Program, HarmonyOS
Language: Simplified Chinese, English, Traditional Chinese
Operating Environment: 0~40°C, 0~85%RH (no condensing), Altitude < 2000m
Storage Environment: -20~50°C, 0~85%RH (no condensing)
Standard Accessory: Power Adapter, USB Cable, User Guide, SQCX PC Software(Download from office website), White and Black Calibration Cavity, Protective Cover, Wrist strap, Aperture
