Pitch: 2 mm (0.079 in)
Wire Gauge: 26 AWG to 24 AWG
Unit Weight: 2.302 g
Housing Color: Black
Latching Type: Latched
Contact Gender: Pin (Male)
Current Rating: 3 A
Mounting Angle: Straight
Mounting Style: Cable Mount / Free Hanging
Number of Rows: 1 Row
Voltage Rating: 32 V
Contact Plating: Gold
Contact Material: Copper Alloy
Housing Material: Thermoplastic (TP)
Termination Style: IDC
Flammability Rating: UL 94 V-0
Number of Positions: 4 Position
Insulation Resistance: 1 MOhms
Maximum Operating Temperature: + 60 C
Minimum Operating Temperature: - 20 C
