- General data:
Display screen : 5.7 inch TFT color touch screen
Power supply: AC 110 V / 220 V, ± 10%, 50 / 60 Hz ± 5%(default AC 220 V 50 Hz)
Fuse: 6 A
Max. Power consumption: 100 W
Memory space: infinite（PC）
Communication mode: Ethernet, RJ 45
External control: D-sub 25 p
External trigger input: BNC, 5V TTL
CRO trigger output: BNC, 5V TTL
Input: BNC, 5V TTL
Warning LED: 0-220VAC 10A/0-48VDC 3A
Depending on external signal lamp
Safety circuit: Test only can be started when it is closed
Failure test: Display on LCD and interrupt the work at failure case
Working indicator: LED, LCD front panel display
Grounding connection : Flat ground line
Size: 19 inch / 4U
Weight: Approx. 15 Kg
Temperature: 15 - 35℃
Humidity: 45% - 75%
Air pressure: 86 kPa - 106 kPa
- Impulse voltage test as per IEC 61643- 1 & GB/T 18802.1:
SURGE module
Standard: IEC 61643-311、GB / T 18802.311
Test voltage: 500V～4500±10%
Voltage waveform: Front time: 1.2 μs ± 30 %
Time to half value: 50 μs ± 20 %
Source output impedance: 500ohm
Output polarity: +/-
Pulse cycle: 10s-99s
Number of test: 1 - 999次
Trigger mode: Automatic, manual and external
