- Technical Parameters:
Standard:
GJB151B-2013
MIL-STD-461E-1999
Test Voltage (Vmax): 6000 V（DC Hz～60 Hz）
Test Current (Imax): 3000 A （DC Hz～60 Hz）
Test Terminal: SHV-BNC Type
Inductance: 50 μH
Coupling Capacitor: 0.25 μF
Impedance Frequency Range: 10 kHz～10 MHz
- General Parameters:
Cabinet Dimension: 1816 mm (L)*960 mm (W)*1076 mm(H)
Weight: Approx. 430 Kg
Ambient Temperature: 15℃-35℃
Relative Humidity: 45% - 75%
Atmosphere Pressure Range: 86 kPa – 106 kPa
